Pigs and Minipigs in Biomedical Research

Pig and minipig PBMCs provide reliable immune models, enabling translational research, drug testing, immunotherapy, and personalized medicine.

In biomedical research, pigs and minipigs serve identical roles as animal models, particularly due to their physiological and anatomical similarities to humans. However, significant differences between them influence their specific applications, ease of handling, and ethical considerations in laboratory settings. Standard pigs (such as domestic farm breeds) grow quite large, typically reaching weights of 300–500 kg. Minipigs, such as the Göttingen, Yucatan, and Sinclair breeds, have been selectively bred to remain smaller, generally weighing between 30–70 kg as adults. Their smaller size makes them more practical and cost-effective to house in research facilities, and they are easier for researchers to handle during studies.

Pigs are often used when larger organ or tissue samples are needed, or in studies where their rapid growth may be an asset. Minipigs maintain a high level of genetic uniformity, an advantage in clinical research because it reduces variability in study results. Minipigs also have a slower growth rate which is beneficial for long-term studies where consistency in physiology over time is important.

Standard pigs are frequently used in agricultural and veterinary studies, as well as in large-scale preclinical studies where a human-equivalent organ size is required, such as in cardiovascular, orthopedic, and gastrointestinal research. Minipigs are primarily used in human biomedical research, including toxicology, pharmacology, and dermatology. Their skin structure is closer to human skin, making them ideal for dermatological studies, wound healing, and drug delivery research.

Book Consultation

Pigs/Minipigs PBMCs

Pig or minipig peripheral blood mononuclear cells (PBMCs) have been used in clinical research because they offer several advantages, mainly due to their similarities to human immune cells. Other benefits have been identified as listed below.
ezgif-8ac968f9137b2e

Similarity to Human Immune System

Pig/minipig PBMCs share similarities with human immune cells in terms of cellular composition, which makes them consequential for studying immune responses to predict human immune system functions.

ezgif-84d613d19d7090

Model for Translational Studies

Pig/minipig PBMCs serve as a robust model for evaluating immune system reactions in drug testing, immunotherapy, and vaccine development, helping to predict responses in humans more accurately than rodent models.

ezgif-8d6c262f0a20a2

Compatibility with Human Genome

The pig/minipig genome is closely related to the human genome, meaning gene expression studies using pig/minipig PBMCs are more translatable to human genetics, facilitating studies in gene expression and immune modulation.

ezgif-49d282e9dfaf92

Ethical and Easy to Source

Pigs and minipigs can be bred and maintained in controlled environments, and their PBMCs are easier to source than human PBMCs, providing a more ethical and readily available resource for large-scale studies.

ezgif-849ab8f16e55ce

Reduced Need for Whole-Animal Testing

In vitro studies with pig/minipig PBMCs can reduce the need for full-scale animal testing, as PBMCs provide a more ethical, cost-effective way to assess immune functions and drug effects.

ezgif-100ee6b73bd568

Standardized Techniques and Protocols

Beagles are widely used in research, thus beagle PBMCs offer an ethical alternative to intrusive whole-animal experiments. Since beagles are easy to collect samples from due to their calm temperament, a steady supply of PBMCs for long-term studies is an advantage.

ezgif-8fddce69cb2da3

In Vitro Modeling for Personalized Medicine

By culturing pig/minipig PBMCs in vitro, researchers can model cellular responses to drugs, immune challenges, and genetic modifications, facilitating advancements in personalized medicine and immunotherapy.

Want to learn more?

To learn more or inquire about Pig / Minipig PBMCs, click here!

Learn More

PIG/MINIPIG PBMC Preparation

ezgif-42d29bb2e23be9

Animal Blood Collection

As required by institutional and ethical guidelines, the animal is anesthetized before blood collection. Blood collection can be accomplished depending on the size of the animal. For small animals such as rats and mice, blood is typically collected from the tail vein, retro-orbital sinus, or by cardiac puncture. For larger animals such as non-human primates, blood is commonly collected from a vein, mainly the saphenous or femoral vein. To prevent clotting, an anticoagulant is added immediately to the blood. Heparin or EDTA is usually used as anticoagulant. The blood is then gently mixed by inverting the tube several times. Vigorous shaking is avoided to prevent hemolysis.
ezgif-4a3db96a4bd709

Dilution of Blood

After addition of the coagulant, the blood is diluted with an equal volume of PBS or sterile saline. This step enables the reduction of cell density to facilitate better separation in the gradient. The solution is then gently mixed by inverting the tube.
ezgif-828e22e17ce422

Density Gradient Centrifugation

A density gradient medium is prepared by adding Ficoll-Paque or Histopaque to a sterile 15 mL or 50 mL centrifuge tube. Approximately 3 mL of density gradient medium per 10 mL of diluted blood is then used. The diluted blood is then layered carefully on top of the density gradient medium. By adding blood along the side of the tube using a pipette, mixing of the mixture is avoided. Next, the mixture is centrifuged at 400 x g for 20-30 minutes at room temperature. Gentle layer separation is ensured by not using the centrifuge brake.
ezgif-8fddbd55dadb7c

Collection of PBMC Layer

The PBMC layer is identified based on its position alongside three other components. The top layer is composed of plasma. The second layer is thin and white, representing the PBMC layer. The third layer is made up of the density gradient medium which is either Ficoll or Histopaque. Finally, the fourth and bottom layer is composed of red blood cells. The second layer, which is the PBMC layer, is carefully harvested using a pipette and then transferred into a new, clean 15 mL centrifuged tube.
ezgif-85d25c4e338001

Washing the PBMCs

Once the PBMCs have been collected, PBS or culture medium is added to dilute the Ficoll or Histopaque. Next, the solution is centrifuged at 300 x g for 10 minutes at room temperature to pellet the PBMCs. After discarding the supernatant, the cell pellet is gently resuspended in fresh PBS or culture medium. This is followed by two more steps of washing to make sure no Ficoll/Histopaque and other contaminants remain.
ezgif-88f2267af3ebd8

Counting and Viability Assessment

To measure viability, cells are first counted using a hemocytometer or an automated cell counter. The cell concentration can be adjusted depending on downstream experiment requirements. Then, cell viability assessment is performed using tryphan blue staining or another similar method. Ideally, the viability of PBMCs for functional assays should be above 90%.
ezgif-8ca007497a6a9b

Storage/Immediate Use

If the freshly collected PBMCs are to be used immediately, cells are resuspended in an appropriate medium or buffer for further processing for techniques such as flow cytometry, cell culture, etc. If the PBMCs are to be stored for later use, the cells are frozen in a cryoprotective medium such as 10% DMSO in fetal bovine serum and then gradually cooled to -80°C before transferring to liquid nitrogen for long-term storage.
Request PBMCs Now

Alpaca PBMC-Based Assays

PBMCs are a versatile sample type in preclinical research due to their role in the immune system. Assays using PBMCs help assess immune function, response to therapies, and disease pathophysiology.

Animal PBMCs are also commonly used in preclinical Safety, Toxicology and Translational research to help select the right in vivo model for late preclinial studies.

The following are common PBMC-based assays in preclinical research.

down-chevron

Flow Cytometry

This assay quantifies and analyzes various immune cell subsets within PBMCs, such as T cells, B cells, NK cells, and monocytes.
Flow cytometry is widely used to determine immune status in diseases like HIV or cancer, evaluate immune responses to therapies, and track cell phenotypes in clinical trials.

down-chevron

ELISPOT (Enzyme-Linked Immunospot) Assay

ELISPOT measures the frequency of cytokine-secreting cells, indicating immune activation.
It is often used in vaccine trials or infectious disease research to assess cellular immune responses by quantifying cytokines like IFN-γ, which indicates T-cell activation.

down-chevron

Proliferation Assays

These assays measure the ability of PBMCs to proliferate in response to specific antigens or mitogens.
They are used in immunological research to assess immune responsiveness in autoimmune diseases, vaccine trials, or immunodeficiencies. Proliferation assays help determine immune system activation and potential deficiencies in cell-mediated immunity.

down-chevron

Intracellular Cytokine Staining (ICS)

ICS is used to detect cytokine production within individual cells using flow cytometry.
This assay helps identify specific functional responses, such as Th1, Th2, or Th17 responses, by measuring cytokines like IL-2, IFN-γ, and TNF. It’s particularly valuable in vaccine and immunotherapy studies.

Published Study That Used Alpaca PBMCs

The study by Pernold et al. (2024) titled “Species comparison: human and minipig PBMC reactivity under the influence of immunomodulating compounds in vitro,” explores the use of minipigs as a translational model for studying immune responses and drug effects, given their physiological and immunological similarities to humans. The research focuses on peripheral blood mononuclear cells (PBMCs) from humans and Göttingen minipigs, examining their reactivity to immunomodulatory compounds through T-cell proliferation assays.

Key Highlights of Beagle PBMCs

ezgif-8ba5e035e2c351

T-cell Responses

CD4+ T cells showed higher activation in humans, while CD8+ T cells were more abundant in minipigs.

ezgif-89011428e4b31f

Drug Effects

Immunosuppressive drugs (abatacept, belatacept, rapamycin, and tofacitinib) showed species-specific responses. For instance, abatacept significantly reduced T-cell proliferation in minipigs compared to belatacept, highlighting differences in drug efficacy due to species-specific molecular interactions

ezgif-1f14572baad0a2

Stimuli Dependency

The suppressive effects of drugs varied with the type of stimulation (e.g., concanavalin A, phytohemagglutinin-L, and staphylococcal Enterotoxin B).

ezgif-1c450fad078604

Antigen-Specific Restimulation

  • In minipigs immunized against porcine circovirus 2, all drugs reduced proliferative responses, with rapamycin being most effective.
  • This research underlines the relevance of minipigs as a model for studying immune-modulating drugs and emphasizes the importance of tailoring stimuli and conditions for accurate interspecies comparisons in drug development.
